Compact transporters
CR 340 K
Technical features
Displacement
166 cm³
Dump angle
45°
Body
telescoping
Load capacity
350 Kg
Engine make/model
Emak K 655 OHV
Gearbox
2+2
Speed (km/h)
1st: 1.6 - 2nd: 3.6 - 1st R: 1.4 - 2nd R: 3.4
Lift/dump
manual
Minimum turning radius
700 mm
Body length
93-106 cm
Body width
52-90 cm
Overall dimensions
153x60x90 cm
Weight
140 kg
User's and maintenance manuals
Show all
K500-K800_1_B.pdf - F - GB - I - SK - E - D
Transporter_unif_340-R30_E5.pdf - BIH - CZ - HR - FIN - F - GB - I - MNE - NL - PL - P - RUS - SRB - SK - E - D - UA - H
K500-K800_2_B.pdf - CZ - GR - PL - P - RUS - TR - UA
K500-K800_3_B.pdf - CHI - EST - FIN - LV - LT - H
K500-K800_4_B.pdf - BIH - HR - NL - SRB - SLO - S
Data and illustrations published are not binding where specifications of materials are concerned, given that these will always be subject to technical improvement. Technical specifications given are subject to change without notice, as also are directions relating to general use of the equipment. Certain items are not available in all countries, or are available only on request.
